Compression Tube Fittings



This Fitting are easy to assemble Possesses Unique locking action by back Formula and Resistant to Vibration and Pressure Pulses, Silver Plated Nuts prevent sizing on Stainless Steel and no torque is transmitted to the tube. It is suitable for high vacuum and Pressure Upto 10,000 Rs.2. They are made of Stainless Steel Tubes SS 316,304,3041,306 and are Available in '116' OD To 2 OD. Carbon steel bite Fittings Comprises Of a Special Ferrule which Grip the Pipe in Position And Perceptibly bites into the Pipes surface to Provide Positive Seal. It is also bowed Slightly in the middle and acts as a Spring which Prevents Loosening of the Joint under Vibration And Strain.
Brass Olive Tube Fittings are used In Low Pressure

Functions : This Fitting are Available in Swage lock Type, Ermetto Type, Parker Type, Festo Type, Push in Type and Flare Type.
USES: Pneumatic Or Hydraulic Installation Air Logic, Systems, Chemical Handling, Centralized Lubrication Systems, Low Pressure Hydraulics, Gas Water And Fluid Lines.

PRESSURE:

S.S.Fittings : Upto 10,000 PSI
C.S.Fittings : Upto 10,000 PSI
Brass Fittings : Upto 10 Kg.
Size : 1/16" OD To 2" OD
1/8 BSP To 2"BSP
Temprature : 40 0 To 360 C

Hydraulic Hose Pipes (Pholofrom Hydrofit)
High Pressure Hose Pipes are available In Following Types.

SAE 100 R-1 :
Application: Medium High Pressure Hydraulic Oil, Lines, Fuel Oil, Gasoline, Air And Water.
Construction: Tube: Black, Oil Resistant Synthetic Rubber, Reinforcement One Ply Braided High Tensile Steel Wire.
Cover: Oil Weather and Abrasion Resistant Synthetic Rubber.


TEMPERATURE: 40 F To 200 F
SIZE: 3/16" ID TO 25/8" ID
PRESSURE: Testing : 750 LBS/PSI To 6000 LBS/PSI
Working : 375 LBS/PSD To 3000 LBS/PSD

SAE 100- R2 :
Application :
Construction:
Temperature:
Size:
Pressure: Testing 2250 PSI To 10,000 PSI
Working 1125 PSI To 5000 PSI

S. S. Corrugated : For Heat Treatment to any Fluid with Steam Or Hot Oil In the Jacketed Section
these are used. By This Temperature of the Fluid in the Inner hose is raised thereby lowering Its Viscosity
and Permitting free flow Of the Liquid. The High Flexibility Of the Hose is Apt For Angular And Offset Movements. These can also be used as coolant Hose in Compressors and Engines. Mainly For use in Chemical, Pharmaceutical, Petroleum And Engineering Industries.

P. P. Clamp
This Pipe Clamps are for Quick And Easy Pipe Installation.

Materials : Polypropylene and Aluminum Bodies.
Sizes : Light : This Type Of Clamps have a Bottom Yellow Passivated 5mm Thk Plates and Top Side No Plates Fitted With Screws Both Side.
Medium : The Type Of Clamps have a both side Plates and Fitted With Bo Hex Head Bolt Both Side.
Heavy : This Type Of Clamps Have A Both Side 8mm Thick Yellow Passivated 8 mm Thick Plated
Fitted With Heavy Duty Hex Head Bolts Both side.
USES: Product Symbolize Quick And Easy Pipe Installation And Standard of Safety For Clamping.

Pressure: Light : Upto 10 Kg.
Medium : Upto 130 Kg.
Heavy : Upto 410 Kg.
Size : 4 mm To 42mm, ¼ " To 2", 1/8 NB To 2" NB
Material : Polypropylene Or Aluminium.
Temperature : 80 C Max.



Air Filter

This Filters are Consists Of Aluminum Body with the Buna-n-seals And Sintered Bronze Filter Element with Transparent Shutter Proof Poly Carbonate Bowl Or Metal Bowl. Double Action Filtration By Cyclone Separation And Residual Separation Produces 'Clean Air' For All Practical Purposes with Minimum Pressure Drop. Buffer Provides 'Quiet Zone' for Collecting Impurities. Manuel Drain Impendent of Bowl Provides Safety Against Damage Due to excess Tightening Of Drain Cock.


AVAILABLE IN THREE DIFFERENT MODEL. Which are MINI, MIDI, & STANDARD

MODEL  MINI  MIDI  STD
Max.Pressure  7 Kg/Cm2  10 Kg/CM2  18 Kg/Cm2
Temprature  60 C  60 C  80
Port  ¼ BSP  ¼ BSP To ½ BSP  ¼ To 1" BSP



Air Regulators
This Regulators Consists Of Aluminium Body with Working Parts Of Brass With Nylon Reinforced Buna-N-Diaphragm & Rubber Seals. Self Relieving Feature Allows 'Bleed Off' Of Excessive back
Pressure thus Safeguarding Instruments and Equipments on the line. Balance Valve Disks &
Nylon Reinforced Buna-N-Diaphragm gives Instant response Over Prolonged Life Span. Big
Orfice Provides Minimum Pressure drop For high flow Capacities. Large Diaphragm Enable
Effective And Sensitive Pressure Control.


AVAILABLE IN THREE DIFFERENT MODELS. Which are MINI, MIDI & STANDARD

MODEL  MINI  MIDI  STD
Max. Pressure  7 Kg/Cm2  10 Kg/CM2  18 Kg/Cm2
Temperature  60 C  60 C  80 C
Port  ¼ BSP  ¼ BSP To ½ BSP  ¼ To 1 ½" BSP
